A Unit of Idex Corporation

Viking Pump USA is the Pioneer of Gear Pumps, and Trimex World Associates (Pvt) Ltd. is the Exclusive Distributor / Representative of Viking Pumps for Pakistan territory.

We provide complete sales and after-sales solutions for Viking Pumps, please feel free to contact us for Viking Pumps, Spare Parts, and any other services you require.

MARKETS & APPLICATIONS

OIL
Crude Oils • Lube Oil & Greases • Asphalt & Bitumens

COATINGS & SEALANTS
Paints, Inks & Dyes • Adhesives • Caulks

CHEMICALS
Acids & Bases • Alcohols & Solvents • Soaps & Detergents

MACHINERY
Fuel & Lube • Heat Transfer Liquids • Filtration

POLYMERS
Rubbers & Plastics • Fibers & Resins • Polyurethanes

PERSONAL CARE
Lotions & Creams • Toothpaste • Hair & Skin Care

FUELS
Refined Fuels • Biofuels • Liquified Gases

FOODS
Sugars • Chocolate • Oils • Dairy • Meats

VIKING PUMP TECHNOLOGIES

INTERNAL GEAR
Broadest selection of materials, designs, seals, ports and displacements for many applications

Adjustable clearances enable handling viscosities from 28 to 2,000,000 SSU (1 to 440,000 cSt)

Minimal shear with slower speeds

EXTERNAL GEAR
Bearing support on both sides of the gears enables differential pressures to 2,500 PSI (170 BAR)

Motor speed operation eliminates cost of speed reducer

Eliminates lubrication – no external axial or radial bearing required in most applications

ROTARY VANE
Maintains highest possible efficiency because vanes compensate for wear

Simple vane replacement without removing pump from piping

Shaft support on both sides of rotor enable differential pressures to 200 PSI (14 BAR)

INDUSTRIAL LOBE
Non-contacting pumping elements allow extended run dry when using flushed seal

Bi-wing rotors scoop solids instead of trapping them like lobe-type rotors

Developed pressures to 400 PSI (28 BAR) with optional shaft support on both sides of rotors

VIKING PUMP BENEFITS

OPERATES AT ANY POINT ON THE CURVE
High efficiency at full range of speeds.

HANDLES ANY VISCOSITY
Capable of handling 28 to 2,000,000 SSU (1 to 440,000 cSt).

LONG SEAL AND BEARING LIFE
Generally operated at speeds from 250 to 1,750 RPM, for reduced seal and bearing wear.

SIMPLE MAINTENANCE
Seal, head, and shaft replacement can usually be done in place without removing the pump from piping.

ENERGY EFFICIENT
Compare to your current pumps using our pump selector or contact us.

LOW NPSHr
Enables suction lifts or pulling from vacuum vessels.

SELF-PRIMING
Enables priming if pump is above liquid level. Some Viking pumps are capable of suction lifts up to 20 ft (6 m).

REVERSIBLE DIRECTION OF FLOW
Use same pump for loading and unloading or line stripping.
